Siemens, 2008-2016 H-D Twin-Cam; 2021 Polaris RZR Turbo S 1000

LIST PRICE is each (1) FUEL INJECTOR

• Siemens Deka IV fuel injectors

• UTV; ATV; Weber/Harley-Davidson, Electra Glide, Street Glide, Road Glide, Road King, 2008 Ultra


• 2021 Polaris RZR Turbo S 1000 - Twin cylinder 168HP


• Price listed is for a single injector (see drop-down menu for options)


• Purchase two of the same flow rate guarantees a matched-pair



Body Design: Composite plastic, black
Injector type: Top feed, saturated

FLOW RATES:

• U420: 450cc, 3 BAR, 6.0 gps; 4 BAR, 6.5 gps
• U646: 650cc, 3 BAR, 7.7 gps; 4 BAR, 8.69 gps
• U845: 845cc, 3 BAR, 10.0 gps; 4 BAR, 11.5 gps

Length, overall: 47 mm
Length, top to lower seal stop: 33.5 mm
Diameter: 16 mm
Fuel rail o-ring: Viton, 14.5 mm
Resistance: 12.5 Ohms
Electrical connector type: EV-1

FLOW CHART: Each set is sold with a complete and unique flow-data chart indicating individual static flow rates at 3.0, 3.5, and 4.0 BAR.
As well as 3.0 BAR dynamic pulse testing for idle (15% duty-cycle) and 50% duty-cycle.
Along with a complete dead time off-set (latency) table. Flow matching was done with industry-standard equipment of the highest quality.
The tests were performed at varying temperatures to achieve realistic results.
Linear tuning with excellent low-end, and idle rpm.
Fiveo is the only fuel injector seller that can claim this level of technology.
